TEEBOX

Connecting solutions with protected boxes

Modular solutions. Maximum user flexibility

• TEEBOX installs terminal blocks from the TEEBLOCK family and other standard terminal blocks
• The product versatility allows the customer to use it in various applications: with terminal blocks, electronic circuits, corrugated conduits and other applications

Cares of details. Safety and reliability for your installation

• The SEBS gasket is co-moulded with a perfect mechanical and chemical adhesion onto the cover of the box to guarantee a valid protection from atmospheric agents (water and dust)
• Knurled clips improve safety locking onto the cable and avoid accidental seal removal
• The base and the cover are co-moulded through an high mechanical  resistance hinge

Interchangeable components. Maximum safe locking and versatility

• Incorporated cable glands guarantee the perfect isolation of the product and safe locking of the installed cable
• Seals are available in different versions to guarantee a safe closure and adherence to the different type of cable commercially available
• For soft cables (silicon or rubber) or small section cables, the adaptors are available to improve the rubber seal compression on the cable

Product innovation is added value for our partners

• The TEEBLOCK current distributor installs into TEEBOX solutions for a total protection
• The wiring is intuitive and guarantees the right connection of cables according to the right polarity
• Easy to install and time-savings, it avoids the top of wires to be twisted

Extra-flat terminal block for particular installation

• Extra-flat terminal blocks (13mm thickness) in 2 and 3 poles
• Nichel plated brass inserts with zinc passivated steel captive anti-screw screws
• Quick locking and unlocking through a simple pressure of the screwdriver on the hooking clip
• Anti-tearing fins to improve safety locking of cable
• approved

TEEfamily offers humidity resistance. The use of resin.

• Avoids moisture condensation inside the electrical connector
• Ensures integrity and functionality of your equipment over time
• Resists to temperatures from –50°C up to +110°C
• Techno electrical connectors provided with resin upon customer request

Milan Stock Exchange
(External Lighting)

Lighting for Interiors
(Internal Lighting)

Connection of Lamps
(Internal Lighting)

IMAGES

SERIES

POLES

IP GRADE

TECHNICAL SHEETS

INSTALLATION INSTRUCTIONS

TH100

2-3

IP20

see
technical sheets

TH110

2

IP44

TH110

3

IP44

TH200

-

IP54
IP67

TH209

-

IP54
IP66
IP68 (5m)

TH211

-

IP54
IP65

TH219

-
